1800mm Width 200 m / Min Toilet Paper Roll Cutting Machine

Product Details:

Place of Origin:	CHINA
Brand Name:	YU SHENG DA
Certification:	CE
Model Number:	YD-TPM-I

Payment & Shipping Terms:

Minimum Order Quantity:	1 Set
Price:	Negotiable
Packaging Details:	We use three-ply board to pack the toilet paper machine into standard export wooden cases and provide you the Fumigation Certificate for free
Delivery Time:	40 Days After Down Payment
Payment Terms:	L/C, T/T
Supply Ability:	10 Sets Per Month

Contact Now

Detailed Product Description

Raw Paper Width:	1800mm	Speed:	200m/min
Product Type:	Toilet Tissue	Processing Type:	Paper Slitting And Rewinding
Perforating Size:	90-500mm	Lamination:	Point To Nest
Voltage:	380V, 50 HZ OR CUSTOMERIZED	Dimension(lwh):	620022002200mm
After-sales Service Provided:	Engineers Available To Service Machinery Overseas, Video Technical Support, Online Support, Field Maintenance And Repair Service, Field Installation	Condition:	NEW
Warranty:	One Year	Power(w):	7.5KW
Product Type:	Toilet Paper Making Machine	Processing Type:	Toilet Paper Making Machine
High Light:	1800mm width Toilet Paper Roll Cutting Machine , 200m/Min Toilet Paper Roll Cutting Machine , 1800mm width toilet tissue paper making machine

Custom Printed Toilet Paper Roll Cutting Machine With Embossing System

Description

Full Automatic Toilet Roll Embossing Point to Point Lamination Machine

is to perforate and cut the raw paper into various sizes according to the requested. The finished product is neat, in good order and with equality tension. It has the feature of compact structure, easy and stable operation, less electricity consumption. This equipment is adjustable to meet the requested finished product. This model is the ideal equipment for paper making factory and paper processing factory.

This machine is consist of stand of raw material, paper conveying unit, embossing unit, perforating unit, rolling unit, electricity control and cutting system

Equipment Function & Character:

1. Unwinding of jumbo roll paper is pushed and fed by flat belt and its feeding speed and tension

controlled by a stepless speed regulator.

2. The component are driven through synchronous belt, the perforating distance and rolling tension

are adjustable.

3. Machine bracket and perforated knife roller are high in rigidity, with good anti-seismic and stable,

brisk operation.

4. Bearing, electric components and synchronous belt are Chinese famous brands.

* One set of embossing roller and one set of glue applying unit can be added additionally as per cliet’s requirement, it can produce kitchen towel. 1-3 color printing device (soft plate printing ) can be added additionally by client’s requirement, it can produce toilet paper or kitchen towel with printed pattern.

Parameter

Machine type	1092	1575	1760	2200	2500	2800	3000	3200
Max width of raw paper	1300mm	1800mm	2000mm	2200mm	2500mm	2800mm	3000mm	3200mm
Outer Dia. of raw paper	1200mm(other size to be specified)
Paper unwinding stand	1-3 layer (The Qty. of raw paper rolls to be specified)(to be ordered)
Inner Dia. of raw paper core	3”(76.2mm)(other size to be specified)
Parameter setting	HMI Operation interface/touched screen
Programming control	PLC
Braking	Electronical /Air pressure control
Machine speed	0-200m/min
Operating speed	0-180m/min
Outer Dia. of finished product	90-135mm(other size to be specified)
Inner Dia. of finished product core	25-50mm
Control of the outer Dia. Finished	Electronical /pneumatic
Perforating	4 pieces of Anvil soft blades, size is 108±2mm (other size to be specified)
Perforating size	Be adjustable
Pneumatic system	3HP Air compressor, with the min. pressure is 5kg/cm2pa(supplied by user)
Control voltage	Stable voltageDC24V
Mechanical structure	Wall plate type
Mechanical transmission	Stepless Gearbox
Transmission method	Link Chain
Power	5.5-22kw Variable Frequency speed regulating
Control of perforating	Pneumatic
Additional function(to be ordered)
Embossing	Single embossing, double embossing, steel to steel embossing, pneumatic embossing
Edge –embossing	Special pneumatic edge embossing device
Gluing	Kitchen towel: point to point gluing/point to side gluing
Decorative glueing system	Pattern is as per the embossing design

Technical Requirement

Raw Paper

(1) Size: Diameter≤1100mm, (Raw Paper Diameter*Width);

(3 )Inner Diameter: 76.2mm

Paper-feeding part

(1) Three Layers and Belt to deliver paper and controlled by Pump;

(2) Three pieces original axis with Tension clamp (3 inch paper core and Shaft sleeve); Size adjustable;

(3) Pneumatic Loading Paper Device

(4) Raw Paper Manual Adjustment

Automatic coreless device

Embossing Part

(1) One set steel to rubber embossing unit (Embossing pattern offered by buyer)

Rewinding Part

(1) Inner Diameter Adjustable Rang: 15mm-60mm

(2) Diameter of finished products: 90-130 mm

(3) Full automatic adjust rewinding perforation size

(4) Using Upper leading paper type rewinding finished products and jog button to lead raw paper

(5) Using the international advanced PLC computer programming technology, Variable frequency speed regulation and HMI interface

(6) Sealing: automatic trimming, adhesive, sealing

Control part

(1) Emergency Device;

(2) Voltage: AC380V 50HZ Main Motor 7.5KW,

(3) Air pressure required less than 0.5 MPA (Supplied by the user)

(4) Electromagnetic speed regulating device

Electrical Parts and other Parts brand

NO	Name	Brand	Original Place
1	Frequency Panel	Siemens	Germany
2	Motor	Siemens	Germany
3	Pneumatic Parts	Schneider	Germany
4	Knife bearing	NSK	Japan
5	Steel	SKD	Japan
6	Touch Screen	Delta	Taiwan

Factory Sale Low Price Tissue Paper Production Line Toilet Paper Making Machine For Sale

Features:

Automatic High Speed Toilet Paper/ Maxi Roll Rewinding Machine is for toilet paper roll/maxi roll processing.
Machine have core feeding unit, can do both with and without core. Raw material from jumbo roll after full embossing or edge embossing, then perforation, end cutting and spray the tail glue become a log. Then it can working with cutting machine and packing machine to become the finished products. The machine is controlled by PLC, people operate it through touch screen, the whole process is automatic, easy to operate, lower the man cost. And Our machine can special-made according to clients' requirements.

Specification:

Model	1092B	1575B	1760B	2150B	2200B	2500B	2800B
Jumbo Roll Max. width	1350mm	1750mm	1880mm	2000mm	2150mm	2400mm	2750mm
Max. Jumbo Roll diameter	2-3 stands (pls specify when order) Paper gram weight 13-16 g/m2
Jumbo Roll Standings	Standardφ3"(76.2mm) (Other sizes specified)
Data setting	HMI
Programming controller	PLC, touch screen
Operate Speed	0-230m/min 15000-25000 rolls/8hours
Finished Log Outer dia.	φ90-140mm
Finished Log Inner dia.	φ38-76mm
Perforation Distance	100-150mm
Mechanical driving	Driving by Stepless gear box
Air -system	3HP air compressor, min. pressure 5kg/cm2pa ( provide by user)
Main driving	Frequency conversion speed regulation 7.5-15KW 380V,50HZ
Embossing unit	Steel to rubber
Dimensions	6x3x1.7 (length x width x height);(m)
Weight	3T-4T(depends on the Model you have )
Options:
Embossment Roller	Plane, Single Set, Double Sets Can be ordered
Color Printing Unit	1-2 Colors can be order
Lamination Unit	Can be Ordered
Edge-Embossing Line	Steel to Steel Operate by Pneumatic
