3000 pieces / Min Napkin Folding Machine
| Brand Name: |
YU SHENG DA |
| Model Number: |
YD-NP-I |
| Certification: |
CE |
| Place of Origin: |
China |
| Minimum Order Quantity: |
1 Set |
| Price: |
negotiation |
| Payment Terms: |
T/T |
| Supply Ability: |
10 sets per month |
| Delivery Time: |
60 working days after received your payment |
| Packaging Details: |
wooden pallet at the bottom and plastic packing for the machines |
Feature
1. Speed: 3000sheets/min
2. Folding Type: 1/4 and 1/8 or 1/6 or M fold or Two folding Type
3. Embossing: steel to steel or steel to paper.
4. Lamination: Point to Point or Nested
5. Glue: Henkel Glue
6. Color Printing: Two color printing
7. Printing Model: Flexo Printing
8. Printing Ink: Water-Based Ink
9. Printing Plate Material: Aniline Plate
10. Important parts Bearing: NSK(Japan)
11. Important parts Steel: SKD(Japan)
12. PLC: Delta
13. Frequency Converter Delta
14. Pneumatic Parts AIRTAC
15. Photoelectrical switch (magic eye) German SICK
16. Anilinox Roller for Printing Unit: Ceramic one 300 lines
17. Motor: SIEMENS
18. Pneumatic Parts AIRTAC
19. Photoelectrical switch (magic eye) Omron
20. 300 Lines ceramic roller
21. 20mm thickness wall board plate for back stand
22. 40mm thickness wall board plate for embossing unit and color printing unit
23. 30 mm thickness wall board plate for cylinder folding parts
24. Max outer Dia. Of raw paper 1200mm
25. Inner Dia. Of raw paper core 3’’
26. Tissue Material: one ply:17-26g/s2 Two ply:16-22g/s2
Parameter
| Open size of finished product |
200*200-430*430mm (to be specified) |
| Diameter of Raw Paper Roll |
1100mm(other size to be specified) |
| Inner Diameter of Paper core |
76.2mm(3 inch) (other size to be specified) |
| Capacity |
3000pieces/min |
| Counting Device |
Electronic Counting |
| Embossing Roller |
Woolen Roller |
| Power |
Frequency Conversion Speed Regulator |
| Calendaring |
Steel to steel or steel to rubber |
| Embossing unit |
Felted roller, woolen roller, Rubber roller |
| Color Printing |
1-2 color |
| Dry Device |
Hot Wind Heating System |
Export Details
1. Delivery time: 60 days
2. Load port: Shenzhen Port(China)
3. Packing: In standard export wooden cases
4. Container: 1 x 20 feet container (It depends on the quantity of the machines).
5. Machine installation and operation training: The seller should dispatch professional technicians and engineers to buyer’s plant to install the machine and train the workers. The round air ticket, accommodation and salary should be paid by buyer.
6. Warranty period: One year(Except easy damaged parts), and will provide long term services including providing spare parts at low price and will heart and soul help the buyer to solve any problem may occur.
Introduction of main parts
Raw Paper
(1) Size:Diameter<1000mm
(2) Material:13-15g/m22 ply,18-22g/1 ply
(3) Inner Diameter:76.2mm
(4) Folding Size:The Buyer Offers the Sample
Paper-feeding part
(1)One Layer and Belt to deliver paper and controlled by Pump;
(2)Raw Paper Manual Adjustment;
Embossing Part
(1)One unit steel to woolen Roller(Patter get confirmation from the buyer)
(2)Mechanical pressure control
(3)cotton cloth and paraffin oil Cleaning Device
Folding Part
(1)Leading Paper Roll Function, the folding tension of the fore part adjustable
(2)Counting Device: Pneumatic dislocation type
(3)Capacity:0-800pieces/min/line
Control Unit
(1)Frequency Conversion Device
(2)Automatic Counting Function
(3)Emergency Device
(4)Voltage:AC380V 50HZ Main Motor 2.2KW,
(5)Air pressure required less than 0.5 MPA(Supplied by the user)
Spare Part
| No |
Items |
Quantity (piece) |
| 1 |
Male inserter knife |
2 |
| 2 |
Band Saw |
6 |
| 3 |
grinding wheel |
5 |
| 4 |
One tool box |
1 |
Electrical Parts and other Parts brand
| NO |
Name |
Brand |
Original Place |
| 1 |
Frequency Converter |
Delta |
Taiwan |
| 2 |
Motor |
Siemens |
Germany |
| 3 |
Pneumatic Parts |
Airtac |
Germany |
| 4 |
Knife bearing |
NSK |
Japan |
| 5 |
Steel |
SKD |
Japan |
