Place of Origin: | Dongguan, Guangdong, CHINA |
Brand Name: | YU SHENG DA |
Certification: | CE |
Model Number: | YD-NP-I |
Minimum Order Quantity: | 1 |
---|---|
Price: | Negotiable |
Packaging Details: | Wooden packing |
Delivery Time: | 45 days after down payment |
Supply Ability: | 2 sets per month |
Folding Type: | 4 FOLD | Embossing: | Steel To Paper Or Steel To Steel |
---|---|---|---|
Speed: | 2200 Sheets Per Min | Lamination: | Point To Point Or Point To Nest |
Color Printing: | 1 To 4 Color Printing | Frequency Converter: | Delta |
Voltage: | 380V, 50 HZ OR CUSTOMERIZED | Dimension(l*w*h): | 3200*1000*1800mm |
After-sales Service Provided: | Engineers Available To Service Machinery Overseas, Video Technical Support, Online Support, Field Maintenance And Repair Service, Field Installation | Condition: | NEW |
Warranty: | One Year | Power(w): | 5.5KW |
Product Type: | Paper Folding Machine, Pulp Molding Machine, Embossing Machine, Paper Making Machine, Napkin Making Machine | Processing Type: | Paper Folding Machine, Pulp Molding Machine, Embossing Machine, Paper Making Machine, Paper Towel Making Machine |
Application: | Napkin Folding Machine To Produce Napkin Paper | Automatic Grade: | Automatic |
High Light: | 4.5KW Tissue Paper Printing Machine,2200 Sheets/Min Tissue Paper Printing Machine,4.5KW napkin tissue paper making machine |
4.5KW 2200 Sheets / Min Tissue Paper Printing Machine / Napkin Tissue Paper Making Machine
4.5KW 2200 Sheets / Min Tissue Paper Printing Machine / Napkin Tissue Paper Making Machine is to produce napkin tissue from big roll. The process includes mbossing , folding , cutting and so on process. The size for the machine vary from 200mm to 430mm to be customerized. The machine is customerized and additional function like color printing and lamination can be specified. The speed for the two deck napkin making machine is 3000 sheets / min for 200mm size and 2200 sheets / min for 300mm size.
Product unfold size | 400*400mm |
Product fold size | 200*200mm |
Raw material jumbo roll size | 1100 mm |
Jumbo roll paper core diameter | 76.2 mm |
Working capacity | 350~450 sheet/min |
Color printing | Can choose |
Embossing unit | Steel to wool |
Counting unit | Electronic counting |
Machine power | 4.5KW |
Dimension | 5200X900X1500mm |
Weight | About 3600kGS |
NO | ITEM | QUA |
1 | Plastic male knife | 4 |
2 | Band Saw | 2 |
3 | Tool Box | 1 |
4 | Grinding Stone | 4 |
1.This model is fit for folding non-woven fabrics and napkin paper, it eliminate the pollution of smeary, iron scrap and belt scrap caused by folding transmission and operation of machine.
2.The modeling is beautiful, it uses little space, the rotating electric box makes up the disadvantages of the whole machine.
3.The type of equipment is desktop type, it makes users feel easy and convenient,it has the characteristics such as the transparency is high ,the paper leading distance is short, the maintenance of machine is convenient
4.The most important function of the model after change is that makes the best use of the available space in the heart place. The advantage is:paper napkin machine
a. It strengthened the stabiliy of the heart place and improved the running speed.
b. The closed function is perfect, it can block paper scraps. It makes the paper scraps separate with principle machine and transmission so that it can be cleaned clearly.
c. It extends the working life of the heart place and reduces the meaningless damage.
d. The model of machine is general , it equipped with single roller and double roller embossing , single color and multicolor printing,the structure is compact and reasonable.(it depends)
5. Double-color local gravure printing(print logo ,the printing area is smaller than the whole area of napkin paper)
