Nest Lamination 380V 50Hz Fully Automatic Tissue Paper Making Machine

Nest Lamination 380V 50Hz Fully Automatic Tissue Paper Making Machine

Nest Lamination 380V 50Hz Fully Automatic Tissue Paper Making Machine
video
Nest Lamination 380V 50Hz Fully Automatic Tissue Paper Making Machine
Product Details:
Place of Origin: CHINA
Brand Name: YU SHENG DA
Certification: CE
Model Number: YD-FTM-I
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Price: Negotiable
Packaging Details: Wooden packing
Delivery Time: 40 Days after down payment
Payment Terms: L/C, T/T
Supply Ability: 10 Sets Per Month
Contact Now
Detailed Product Description
Bearing: Made In Japan Speed: 4800 Sheets/min
Motor: Siemens Touch Screen: Siemens
Steel: NO 45 Steel Structure: Wall Board
Voltage: 380V, 50 HZ OR CUSTOMERIZED Dimension(l*w*h): 6200*2200*2200mm
After-sales Service Provided: Engineers Available To Service Machinery Overseas, Video Technical Support, Online Support, Field Maintenance And Repair Service, Field Installation Condition: NEW
Warranty: One Year Power(w): 7.5KW
Product Type: Facial Tissue Making Machine Processing Type: Facial Tissue Making Machine
High Light:

Nest Lamination Fully Automatic Tissue Paper Making Machine

,

380V Fully Automatic Tissue Paper Making Machine

,

Nest Lamination tissue paper folding machine

Embossing Printing Tissue Paper Cutting Machine Point To Nest Lamination

Description

SIEMENS PLC Facial Tissue Box Drawing Machine Point to Nest Lamination is with embossing, folding unit, counting unit  and cutting , convey, automatic boxed and automatic sealing box in one body. This equipment adopt PLC, frequency control and equip with touch type multi-picture man and computer interface operation system. Adopt synchronization belt driving, speed-change machine driving for complete machine, which make the machine can suitable for various kind of raw material’s requirement , and improve the quality and efficiency. The operation flow of this production line is easy, high production efficiency and made perfect production. This production reduce the production operation and packaging person which save the expense of production and management.


Specification

Jumbo Roll Dimension

   1,200 mm(W)


Jumbo Roll Diameter

   1,200 mm(∅)


Jumbo Roll Material Quality

   Paper Basic Weight: 13~15 gsm/2 ply
   Paper Material: 100% Pure Paper
   Jumbo Roll Paper Core: 3 inches
   Jumbo Roll Unit: 2 units


Interfold Style

   V Fold (2 ply)


Unfold Dimension

   200mm(L) x 200mm(W)


Interfold Dimension

   100mm(L) x 200mm(W)


Slitting Kinives

   10 units


Design Machine Speed

   60~80 M/min


Design Product Capacity

   4,800 sheets/min



Main Specification



  1. Speed: 4800sheets/min

  2. Folding Type: Interfold

  3. Edge Embossing

  4. Frequency Converter Delta

  5. Motor: Siemens

  6.  Pneumatic Parts AIRTAC

  7. 20mm thickness wall board plate for back stand

  8. 40mm thickness wall board plate for embossing unit

  9. 30mm thickness wall board plate for cylinder folding parts

  10.  Photoelectrical switch (magic eye) Omron

Electrical Parts and other Parts brand


NO

Name

Brand

Original Place

1

Motor

Siemens

China

2

Pneumatic Parts

Omron

Germany

3

Vacuum Pump

Longtech

Taiwai

3

Frequency converter

Delta

Taiwai



Product Description

High Quality Facial Tissue Machine Paper Product Making Machinery

Nest Lamination 380V 50Hz Fully Automatic Tissue Paper Making Machine 0



Features:

Facial tissue making machine working flow:The jumbo rolls which have been slit into the desired width are cut by the slitting cylinders,and then interfolded into interoverlapped rectangular facial tissue sheets.
This machine adopts independent servo motor drive,and automatic paper tension control automatic marking functings.It featurse of high speed,nice folding and easy operation.

1.Can order steel to rubber embossing rolls,pneumatically separated.

2.Wallboard rack and Machine running stability and extremely good and fast.

3.Pneumatic jumbo roll loading,pneumatic paper driving,stepless speed additionstment,and web tension control.

4.Equipped with roots type vacuum pump for stable running of the machine.

5.Make various products width as requirement.

6.Equipped with edge embossing unit to keep the plise together.

7.The machine will stop when the paper broken.It avoid waste caused by no paper or paper broken.

8.The web can be threaded on the machine by the two jog buttons,It's more safer and easier to thread the web.

1. Specification of Facial Tissue Folding Machine:

Machine Model
SYM-190/6L (Other size to be specified)
Finished Products Unfolded Size
95x(120-210)x2mm
Folding Products Size
190x(120-210)x2mm
Raw Material Width
1260mm
Raw Material Diameter
1200mm
Raw Material Core Diameter
76.2mm
Output Capacity (8 hours)
2000-3000kg
Embossing Unit
Steel to rubber
Edge Embossing
Steel to steel edge embossing, independent pneumatic regulation
Slitting Unit
Pneumatic slitting
Main Servo Moter Power
5.5kw
Unwind Frequency Motor Power
1.5kw (2 units)
Vacuum System
18.5 kw Vacuum pump (Taiwan Roots blower)
Pneumatic System
3HP air compressor,Min. pressure 5kg/cm2PA (Provider by user themselves)
Driving System
Timing belt
Dimension
5870x2800x2207mm
Weight
About 5 tons
Nest Lamination 380V 50Hz Fully Automatic Tissue Paper Making Machine 1
Nest Lamination 380V 50Hz Fully Automatic Tissue Paper Making Machine 2
Nest Lamination 380V 50Hz Fully Automatic Tissue Paper Making Machine 3
Nest Lamination 380V 50Hz Fully Automatic Tissue Paper Making Machine 4

2. Specification of Single Channel Log Saw Cutting Machine:

Nest Lamination 380V 50Hz Fully Automatic Tissue Paper Making Machine 5
Designation
Parameter values
The length of the none cut off facial tissue
minimum 500mm
The Height of tissue
30~130mm
Machine Speed
20~150cut/min
Operating speed
20~120cut/min
Round blade outer diamete
Φ610mm
Paper cutting circular knife top speed
980R/min
Finished products specification
70~300mm
Paper width
70~110mm
Cutting Length
70~300mm
Left-over Length
20~65mm
Power
11KW
Power supply
380V 50Hz
Air source
0.5~0.8MPa
Machine Size
4600*1700*2500mm
Weight of machine
2300~2600kg
Brake
Parameter setting (auto/manual)
Stepping sharpening knife
Parameter setting (auto)
Pneumatic sharpening knife
Parameter setting (auto/manual)
Blow air
without
The total pressure switch
Value (not)
Human-computer interface
DELTA
Frequency changer
DELTA
Servo Drive
DELTA

3. Specification of Facial Tissue Packing Machine:

1. Adopting packing way by wrapping, folding and sealing with compact structure, it makes the package look beautiful and the seal tightened.
2. Controlled by stepless speed regulation, touch screen and PLC, the display on the human-machine interface makes maintenance more simply.
3. Applied with auto-arranging feeding conveyor, it is convenient to connect the conveyor with automatic production line, saving the labor cost to the maximum.
4. It saves much packing material by means of photocell checking, servo tracking, and auto-stop of film feeding without product.
5. High automation, high profession, high efficiency and less trouble.
6. With wide packing size range, various packing sizes can be quickly interchanged.

Tissue sizes:
L: 150-400mm W: 150-200mm H: 35-150mm
Packing speed:
40-70 bags/min
Air supply:
0.5-0.8MPa
Machine weight:
3300kg
Outer dimensions (LxWxH):
5885x3560x1925(mm)
Heating power:
3.6kw
Motor power:
3.6kw
Packing size:
≤230x190x100(mm)
Working noise:
≤78dB
Packing film:
CPP
Power supply type:
380V, 50Hz
Nest Lamination 380V 50Hz Fully Automatic Tissue Paper Making Machine 6
Nest Lamination 380V 50Hz Fully Automatic Tissue Paper Making Machine 7

Final Products:

Nest Lamination 380V 50Hz Fully Automatic Tissue Paper Making Machine 8

4.Specifications of Semi Automatic Two Outlets Multi Bags Packing Machine:

Packing Size
≤500x300x110mm (LxWxH)
≥220x120x90mm (LxWxH)
Packing Speed
10-20 bag/min
Gas Pressure
0.5mpa-0.8mpa
Voltage & Frequency
380V,50Hz,3Phase
Total Power
0.8kw
Weight
1000kg
Overall Dimension
4900x1650x1280mm
Tissue paper bag (one row/two rows)
Tissue paper bag (one row/two rows)
Nest Lamination 380V 50Hz Fully Automatic Tissue Paper Making Machine 9

Final Products:

Nest Lamination 380V 50Hz Fully Automatic Tissue Paper Making Machine 10
Packing & Delivery
Nest Lamination 380V 50Hz Fully Automatic Tissue Paper Making Machine 11
Nest Lamination 380V 50Hz Fully Automatic Tissue Paper Making Machine 12
Nest Lamination 380V 50Hz Fully Automatic Tissue Paper Making Machine 13
